• 40 MHz, 60 MHz, 70 MHz, 100 MHz, 200 MHz and 300 MHz bandwidths
• Sample rates up to 2 GS/s
• Long Memory - up to 1 Mpts/Ch (2 Mpts interleaved)
• Advanced Triggering - Edge, Pulse Width, Video, Slope (Rise Time)
• 7" wide screen display
• 32 automatic measurements
• Multi-language user interface and context sensitive help
• Four math functions and FFT
• USB host and device connections for printers, memory sticks and PC remote control

Long memory, high sample rate and easy to use zoom capabilities

Measure with 32 different parameters including advanced timing measurements and a dashboard view

Basic math plus FFT for advanced waveform analysis

Save waveforms, settings and screen captures to a USB device or directly to a PC

Quick mask testing with on screen result counter

Record and playback up to 2,500 waveform captures

Apply digital filters to isolate specific frequencies or eliminate noise

A variety of basic and advanced triggering for capturing a range of different signals

Save up to 20 waveforms and 20 setups to internal memory

Chose from Real Time, Equivalent Time, Peak Detect and Averaging
