Tektronix/P6046/探頭
- Tektronix/P6046/探頭
- 欲購買或租賃Tektronix/P6046/探頭?請在線咨詢或拔打24小時電話:13715327187
詳細資料:
The P6046 is a self-contained active differential system consisting of a differential probe, amplifier and power supply. Active FET amplifiers at the dual-inputs reduce circuit loading. Combined with the differential processing occuring in the probe head, the P6046 provides superior common mode rejection ratios (CMRR) at high frequencies typically 10,000:1 out to 50 kHz, derating to 5,000:1 at 1 MHz.
Since the P6046 is self-contained, it provides a differential output into a single oscilloscope channel. System controls enable you to select AC or DC coupling, adjust the DC balance and select mV/div from 1 to 200mV (10mV to 2V with attenuator head) in standard 1,2,5 steps.
A slip-on 10X attenuator is also included which increases the maximum input voltage from +/-25V to +/-250V and the common mode dynamic range from +/-5V to +/-50V.
儀器保證:
我們的大多數設備在裝運之前均經過嚴格的質量檢測與校驗。也可申請國家計量證書。
